Item # VMA1240
5 INPUT CHANNEL X (1) 240W OUTPUT CHANNEL MIXER/AMPLIFIER, 70V/100V OR 4O/8OHM
Click image to enlarge
Item # VMA1240
5 INPUT CHANNEL X (1) 240W OUTPUT CHANNEL MIXER/AMPLIFIER, 70V/100V OR 4O/8OHM
- UM: EA
- Estimated Weight: 31.0
- Brand: JBL / HARMAN
The JBL VMA Series consists of mixer/amplifiers designed to support both low impedance outputs (4 ohms and 8 ohms) and high impedance 70V and 100V outputs. These units offer configurations suitable for various commercial audio integration applications.
| Max Output Power per Channel | VMA160 60W, VMA1120 120W, VMA1240 240W |
|---|---|
| Insertion Loss (70V & 100V outputs) | 1dB max |
| Number of Inputs | 5 |
| Number of Outputs | 1 |
| Tone Controls | Bass +/-14dB @ 50Hz; Treble +/-14dB @ 10kHz |
| Input Sensitivity | Mic 5.5mVRMS, Line 1.3VRMS, RCA 130mVRMS |
| Frequency Response | 4/8 ohm output 20Hz-20kHz +/-2dB; 70V/100V outputs 80Hz-15kHz +/-3dB |
| Total Harmonic Distortion (THD) | <0.5% 20Hz-20kHz |
| Signal to Noise Ratio | >76dB |
| Phantom Power | 27VDC |
