Item # VMA1120
VMA 1120: (5) INPUT CHANNEL X (1) 120W OUTPUT CHANNEL MIXER/AMPLIFIER, 100V, 70V OR 4OHM / 8OHM
- MAP: $779.00 / EA
- List Price: $779.00 / EA
- Log in to see if custom discounts apply
- Pkg Qty: 1
- Case Qty: 1
Click image to enlarge
Item # VMA1120
VMA 1120: (5) INPUT CHANNEL X (1) 120W OUTPUT CHANNEL MIXER/AMPLIFIER, 100V, 70V OR 4OHM / 8OHM
- Estimated Weight: 27.0
- Brand: JBL / HARMAN
The JBL VMA1120 is a mixer/amplifier from the VMA Series, supporting low impedance outputs of 4Ω and 8Ω, as well as high impedance outputs at 70V and 100V. It includes features aimed at flexible integration for commercial audio installations.
| Max Output Power per Channel | VMA1120: 120W, 1kHz, ≤ 0.5% THD, into 4 Ω or 8 Ω |
|---|---|
| Insertion Loss | 1dB maximum (70V & 100V outputs) |
| Number of Inputs | 5 |
| Number of Outputs | 1 |
| Tone Controls | Bass ±14dB @ 50Hz; Treble ±14dB @ 10kHz |
| Input Sensitivity | Mic Input: 5.5mVRMS, Line Input: 1.3VRMS, RCA Input (stereo in): 130mVRMS |
| Frequency Response | 4/8 Ω Output: 20Hz - 20kHz, ±2dB; 70V/100V Outputs: 80Hz - 15kHz, ±3dB |
| Total Harmonic Distortion (THD) | Power Amp Output: <0.5%, 20Hz - 20kHz |
| Signal to Noise Ratio | >76dB (Ref. Rated Power, A-weighted) |
| Input Impedance | Mic: 400 Ω, Line: 20 kΩ (balanced), RCA: 50 kΩ |
| Phantom Power | 27VDC |
| Crosstalk | -70 dB (1kHz, volume mid position) |
