SRX812P | 2000W POWERED 2-WAY SYSTEM FEATURING CROWN AMPLIFICATION, NETWORK CONTROL, USER CONFIGURABLE DSP
Item # SRX812P
2000W POWERED 2-WAY SYSTEM FEATURING CROWN AMPLIFICATION, NETWORK CONTROL, USER CONFIGURABLE DSP
Click image to enlarge
The SRX812P is a 12-inch two-way powered loudspeaker from the JBL SRX800 Series. It incorporates JBL drivers and a 2,000-watt Crown amplification system utilizing Crown Front-End DriveCore Technology. The speaker includes user-configurable DSP with V5 Tunings compatible with Vertec and VTX touring systems. It supports HiQnet Network control via iOS and Android applications.
Designed for general-purpose use, the SRX812P is compatible with JBL’s flagship touring systems and supports various configurations for live sound, touring, and installation applications.
Features:
- Rugged design
- Intuitive to use
- Easy to transport
- JBL premium transducers
- Drivecore amplification by Crown
- Full user configurable DSP
- Network control
- JBL engineered application presets
- LCD screen
- Glow in the dark ink on back panel
- M10 suspension points
- Standard 35mm pole cup
- Feet for monitor angle
- Suitable for live performance systems
- Suitable for mobile and fixed DJ systems
| System Type | Self-powered 12” two-way bass-reflex |
|---|---|
| Maximum SPL (1m) | 136 dB |
| Frequency Range (-10dB) | 40 Hz - 21 kHz |
| Frequency Response (±3 dB) | 48 Hz - 20 kHz |
| Coverage Pattern | 90° x 50° |
| Amplifier Design | Class D |
| Power Rating | 2000 W Peak |
| EQ | 20 parametric EQs, speaker delay, 50 preset slots |
| Inputs | Neutrik ¼ - XLR input; Neutrik XLR output |
| LF Driver | 1 x 2272F Differential Drive 12" diameter |
