Item # SLIMPART12ILS
LOW-PROFILE, HIGH-OUTPUT TRI-COLOR (RGB) LED PAR, D-FI USB COMPATIBLE
Item # SLIMPART12ILS
LOW-PROFILE, HIGH-OUTPUT TRI-COLOR (RGB) LED PAR, D-FI USB COMPATIBLE
- UM: EA
- Estimated Weight: 10.0
- Brand: CHAUVET DJ
SlimPAR T12 ILS is a low-profile, high-output tri-color (RGB) LED Par featuring compatibility with the cutting edge Integrated Lighting System (ILS) that makes creating coordinated light shows across different fixture types easy. D-Fi USB compatibility is also featured for wireless Master/Slave or DMX control. From dance floor to studio, SlimPAR T12 ILS is great for on-camera use because of its flicker-free operation. This powerful par offers convenient access to RGB color mixing and static colors with or without DMX. Access built-in automated programs via IRC-6 remote, Master/Slave or DMX.
Features:
- Low-profile, high-output tri-color (RGB) LED Par
- ILS compatibility for use in the ILS ecosystem
- D-Fi USB compatibility for wireless Master/Slave or DMX control
- Convenient access to RGB color mixing and static colors with or without DMX
- Flicker-free operation suitable for on-camera use
- Save time running cables and extension cords by power linking multiple units
- Access built-in automated programs via IRC-6 remote, Master/Slave or DMX
- Fits best in the CHS-30 VIP Gear Bag
- Compact design easily fits inside sticks of TRUSST
| DMX Channels | 3 or 8 |
|---|---|
| DMX Connectors | 3-pin XLR |
| Light Source | 12 LEDs (tri-color RGB) 4.9 W (1.19A , 50,000 hours life expectancy |
| Strobe Rate | 0 to 11 Hz |
| Beam Angle | 17° |
| Field Angle | 29° |
| Illuminance | 3,362 lux @ 2 m |
| Lumens | 1,415 |
| Power Linking | 13 units @ 120 V; 23 units @ 230 V |
| Input Voltage | 100 to 240 VAC, 50/60 Hz (auto-ranging) |
| Power and Current | 43 W, 0.6 A @ 120 V, 60 Hz; 43 W, 0.3 A @ 230 V, 50 Hz |
| Weight | 3.6 lbs (1.6 kg) |
| Size | 8.8 x 8.8 x 9.7 in (224.5 x 225.5 x 246 mm) |
| Bracket Mounting Hole | 13 mm |
| Optional controllers | IRC=6 |
