NANO-MARINE | ULTRA COMPACT LOUDSPEAKER - 3" FULL RANGE DRIVER - 70V OR LOW IMPEDENCE W/"U" BRACKET
Item # NANO-MARINE
ULTRA COMPACT LOUDSPEAKER - 3" FULL RANGE DRIVER - 70V OR LOW IMPEDENCE W/"U" BRACKET
Click image to enlarge
The NANO-MARINE is a compact speaker designed for distributed 70-volt systems, supplemental fills, or stereo satellite applications with subwoofer systems. It features a small form factor while delivering sound output suitable for its size. The design emphasizes high fidelity and speech intelligibility.
| Coverage pattern | 110° Conical |
|---|---|
| Operating frequency range | 136 Hz – 21 kHz (-10 dB) |
| Continuous output | 102 dB SPL |
| Peak output | 108 dB SPL |
| Sensitivity | 89 dB SPL (2.83V input, 1M whole space) |
| Driver complement | 1 x 3" |
| Rated impedance | 8 ohms or 70V taps 20W/10W/5W |
| Power rating | 20W |
