Item # MA-725F-AM
4 X 250W MATRIX MIXER-AMP W/DSP - 6 INPUTS (4 LINE, 2 MIC/LINE LEVEL) TO 4 OUTPUT CHANNELS
Item # MA-725F-AM
4 X 250W MATRIX MIXER-AMP W/DSP - 6 INPUTS (4 LINE, 2 MIC/LINE LEVEL) TO 4 OUTPUT CHANNELS
- UM: EA
- Estimated Weight: 21.0
- Brand: TOA ELECTRONICS
The MA-725F is a 6-input matrix mixer: 4 of its inputs are configured for BGM or other line-level sources, while two balanced inputs are designated for priority sources, such as paging mics or message players. This is coupled in a single chassis with a 4 x 250W (@70 or 100V) Class D amplifier section, capable of driving large speaker compliments with maximum efficiency. It has capability to control by API.
|
Power Source |
100 - 240V AC, 50/60Hz | |
|
Power Consumption |
1350 W (rated output), 200 W (based on cULus standards), 42.5 W (idle), 22 W or less (stand-by) | |
|
Frequency Response |
20Hz - 20 kHz (-3 dB / + 1 dB, LPF OFF) | |
|
Total Harmonic Distortion |
1% or less, at 1kHz, rated output | |
|
Certifications |
cULus 60065, EN60065, EN55032, EN55020, FCC part15 class A | |
|
Input |
Priority 1-2: |
Mic -60 dB/Line -10 dB selectable, 2.2 kO, electronically-balanced, removable terminal block |
|
Line In 1-4: |
-10 dB, 10 kO, unbalanced, 2 RCA jacks (Stereo summing) | |
|
Output |
Speaker 1-4: |
70 V (20 O), 100 V (40 O), removable terminal block |
|
Line Out 1-4: |
0 dB*, 600 O, unbalanced, RCA jack | |
|
MOH: |
0 dB*, 600 O, transformer balanced, removable terminal block | |
|
DSP Preset |
16 presets in 4 banks at each output channel, selectable | |
|
S/N Ratio |
Mic: 60 dB* or more, Line: 75 dB* or more (A-weighted) | |
|
Muting |
Manual mute / Automatic mute | |
|
Mute Hold Time |
50ms - 10 seconds, adjustable | |
|
Priority Level |
PRIORITY 1 > PRIORITY 2 > LINE 1-4 | |
|
Control |
Power: |
ON/OFF switch, Power remote terminal |
|
Priority 1-2: |
MIC/LINE selector switch, Gain control, Assign switch, Auto mute switch, Mute sense control, Manual mute terminal, Mute hold time control, Priority mix switch | |
|
Line In 1-4: |
Gain control, Assign restriction switch | |
|
Output 1-4: |
LINE In 1-4 selector switch, Output gain control, 70V/100V selector switch, HPF switch, DSP bank selector switch, DSP preset selector switch | |
|
Remote 1-4: |
Remote control connector (RJ-45), Remote link switch | |
|
Indicators |
Power: |
1 Power LED |
|
Priority 1-2: |
1 Signal LED, 1 Peak LED | |
|
Line In 1-4: |
1 Signal LED, 1 Peak LED | |
|
Output: |
2 Activated PRIORITY LED, 1 Connected REMOTE LED, 4 Selected LINE LED, 1 Signal LED, 1 Peak LED, 1 Protect LED | |
|
Operating Temperature |
0 to 40 °C degree (32 to 104 °F) | |
|
Operating Humidity |
35% to 80% RH (no condensation) | |
|
Finish |
Panel: Aluminum, hair line, black; Case: Steel plate, black, paint | |
|
Dimension |
420 (W) x 107.6 (H) x 350 (D) mm (16.54" x 4.24" x 13.78") | |
|
Weight |
7.6 kg (16.7 lbs) | |
|
Accessories |
Power cord (2m (5.65ft)) x1, Removable terminal plug (5 pins x 2, 3 pins x 1, 2 pins x 4); Rack mounting bracket x 2, Bracket mounting screws x 4, User manual x 1 | |
|
Option |
Remote Control Panel : WP-700-AM | |
