Item # HPA2408
8CH 2400W COMMERCIAL AMP - 8 X 300W AT 4O, 8O, 25V, 70V, & 100V OPERATION 2RU
Click image to enlarge
Item # HPA2408
8CH 2400W COMMERCIAL AMP - 8 X 300W AT 4O, 8O, 25V, 70V, & 100V OPERATION 2RU
- UM: EA
- Estimated Weight: 34.0
- Brand: ATLAS IED
The AtlasIED HPA2408 is a high-efficiency, eight-channel commercial amplifier designed to deliver robust and reliable performance for demanding multi-zone audio systems. Providing 2400 watts of total output (300W per channel @ 4O), this Class D amplifier supports both low-impedance and 70V/100V distributed audio systems. Each channel is independently addressable, making the HPA2408 ideal for large-scale installations such as stadiums, campuses, worship centers, and commercial facilities. The unit features balanced inputs with global or per-channel operation, front panel level controls with security covers, and fault reporting via GPIO and remote status monitoring. Built with a compact 2RU chassis, advanced protection circuitry, and convection cooling for silent operation, the HPA2408 is engineered for continuous duty in mission-critical AV environments. It’s a top-tier choice for integrators needing scalable, high-powered amplification in a single, space-saving unit.
Whether the application is a large distributed constant voltage sound system or a high SPL sound reinforcement system, the AtlasIED HPA Series is the answer for high power / cost effective reliable amplification requirements.
Whether the application is a large distributed constant voltage sound system or a high SPL sound reinforcement system, the AtlasIED HPA Series is the answer for high power / cost effective reliable amplification requirements.
Features:
- 4O, 8O, 25V, 70V, & 100V Operation
- Each channel load can be independent of the others
- Only requires a 15A AC mains source for 120V operation
- Remote turn on
- Accessory card slots for optional Dante digital network audio cards
- Fault Reporting
- Detented attenuators with security covers
- Stereo or parallel operating modes
- Selectable input sensitivity
- BUSS input with individual channel assignments
- Multistage fan cooling
- Removable air filters
- Wide range AC Mains power supply 100V - 240V with PFC
- Meets Energy Star standards for 1W Standby Mode
| Power Output | 2400W |
|---|---|
| 100V | 8 x 300W |
| 70.7V | 8 x 300W |
| 25V | 8 x 300W |
| 8O | 8 x 300W |
| 4O | 8 x 300W |
| 2O | NA |
| Frequency Response | 20Hz - 20kHz (+0/-1.5dB) |
| THD | <0.15% |
| Channels | Eight |
| Signal to Noise Ratio | >70dB |
| Connector Type | Terminal Block & Phoenix |
| Number of Fans | 1 - Variable Speed |
| Rack Units | 2 RU |
| Height | 3.5" (89mm) |
| Width | 19" (483mm) |
| Depth | 15" (381mm) |
| Voltage Compatibility | Universal |
| Weight | 21.4 lbs. (9.7kg) |
| Finish | Black |
| Warranty Period | 36 months from date of purchase |
