Item # HPA1204
4CH 1200 TOTAL WATT AMP, 300W PER CHANNEL 4 / 8OHM, 70V / 100V, 2 RU
Click image to enlarge
Item # HPA1204
4CH 1200 TOTAL WATT AMP, 300W PER CHANNEL 4 / 8OHM, 70V / 100V, 2 RU
- UM: EA
- Estimated Weight: 28.0
- Brand: ATLAS IED
The AtlasIED HPA1204 is a four-channel, 1200-watt commercial amplifier designed for versatile audio applications, including 70V/100V distributed systems and low-impedance setups. Utilizing Generation II Class D output topology, it delivers high-efficiency performance with sound quality comparable to Class AB amplifiers. The switch-mode power supply ensures stable operation across varying power conditions, and the amplifier supports multiple impedance loads with each channel independently configurable for 4O, 8O, 70.7V, or 100V operation. Additional features include balanced line inputs, remote turn-on capability, fault reporting, and an accessory card slot for an optional Dante™ four-channel digital audio interface. The HPA1204 meets Energy Star standards, consuming only 1W in standby mode, making it an efficient and reliable choice for various professional audio installations.
Features:
- Four Output Channels
- 4O, 8O, 70V, & 100V Operation
- Balanced Inputs
- Dante Accessory Card Slot
- Fault Reporting
- Remote Turn On
- Detented Attenuators with Security Cover
- Auto Sensing 100V-240V~ AC Mains Power Supply
- Meets Energy Star Standards 1W Standby Mode
| Power Output | |
|---|---|
| 70.7V | 4 x 300W |
| 100V | 4 x 300W |
| 8O | 4 x 300W |
| 4O | 4 x 300W |
| 2O | NA |
| 8O Bridged | NA |
| 1O RMS Power Output | NA |
| Frequency Response | 20Hz - 20kHz |
| THD | <0.15% |
| Channels | Four |
| Signal to Noise Ratio | >70dB (A-Weighted) |
| Connector Type | Terminal Block & Phoenix |
| Number of Fans | 1 - Variable Speed |
| BTU All Channels Driven AES | 1486 BTU (70.7V, 120VAC) |
| Max Current All Channels Driven Continuous | 13.63A |
| Rack Units | 2 RU |
| Height | 3.5" (89mm) |
| Width | 19" (483mm) |
| Depth | 15" (381mm) |
| Weight | 21.4 lbs. (9.7kg) |
| Finish | Black |
| Voltage Compatibility | Universal |
| Warranty Period | 36 months from date of purchase |
