The Control 47HC is a high-ceiling loudspeaker designed with a narrow 75° coverage pattern, optimized for environments with high ceilings and significant reverberation. This focused dispersion pattern reduces sound reflections from room surfaces and limits timing discrepancies caused by adjacent loudspeakers, contributing to enhanced speech intelligibility. The Control 47HC shares the acoustic characteristics of the Control 47C/T model, making it suitable for large indoor spaces such as transit centers and convention halls.

• Narrow Coverage Pattern
• Improved Sound Quality in Reverberant Spaces
• Proprietary Conical RBI® Technology for Pattern Control

Frequency Range	55 Hz - 17 kHz
Power Rating	150 W Continuous Program Power, 75 W Continuous Pink Noise (300 W peak)
Sensitivity	93 dB (1 kHz - 16 kHz)
Transformer Taps	60 W, 30 W, 15 W, 7.5 W @ 70 V, plus transformer bypass
Coverage Angle	75° conical, constant directivity
Impedance	8 ohms (in bypass mode)
Maximum SPL	112 dB (low-impedance, 118 dB peak), 111 dB (top 70V/100V tap)
Safety Agency	Suitable for use in air handling spaces per UL1480, UL2043, NFPA90 & NFPA 70; UL Listed; Transformer UL registered per UL1876; IEC60849/EN60849 compliant
Baffle/Rim	ABS baffle with UL94-V0 flame class fire rating
Plenum Usage	Yes, backcan included
