Description:

XB-142 offers a host of specialized broadcast features that normally come at a much higher price, including telephone communication (telco) channels, mic channel ON switch sensing, stereo channel start/cue outputs for playback device control, automatic muting of speaker outputs and much more. XB-142 incorporates new features and styling based on feedback from the many broadcasters who have built their operations around the original XB-14. With a wealth of routing options, dual stereo channels for up to 7 stereo sources, and the addition of a dedicated Audition bus, enhanced microphone preamps and stereo channel gain range, XB-142 satisfies the demands of small radio and internet broadcasters as well as larger studios with multiple rooms. With no less than 27 logic I/O for remote control and 15 configuration switches, XB-142 is a highly flexible solution.

Features:

·        4 mic/line channels

·        4 Dual Source stereo channels

·        2 Telco channels

·        HPF and 3-band, swept mid EQ on mono channels

·        2-band EQ on stereo channels

·        Variable high pass / low pass filters on Telco channels

·        Smooth-ride 100mm faders

·        2-stage, padless pre-amp design

·        Fader-start sensing on mono channels

·        Start/cue logic outputs on stereo channels

·        External meter socket

·        Separate headphones mix for engineer/producer and 2 guests

·        Auto mutes on control room outputs

·        Remote mute facility on mic channels

·        Configurable USB stereo audio in/out

·        Audition bus for auditioning and off-air recording

·        Aux and separate stereo busses for processing/recording

·        XLR main outputs with inserts

·        Input signal and peak metering
