Item # AA50PHD-CE
3-INPUT 50W MIXER AMPLIFIER WITH AUTOMATIC SYSTEM TEST (PHD), CE CERTIFIED
Click image to enlarge
Item # AA50PHD-CE
3-INPUT 50W MIXER AMPLIFIER WITH AUTOMATIC SYSTEM TEST (PHD), CE CERTIFIED
- UM: EA
- Brand: ATLAS IED
CE-listed, six input, 200-watt mixer amplifier designed for distributed business paging and background music (BGM) systems featuring Push Here Diagnostic technology and Remote Input Selection Remote Level control. The AA50PHD-CE is CE certified for use in Europe (220V-240V) and other international locations requiring that safety listing.
Features:
- 50W into 25V/70.7V and 4Ω Loads
- Rear Mounted DIP Switch Allows Mute Receive for Inputs 2 and 3
- Contact Closure Mute Terminals
- Variable Mute Sensitivity Control for Input 1
- Preamp In for External Processors
- Line Output
- Remote Input Select (RIS)
- Remote Level Control
- Input Assignable Zone 2 Output
- Two Unbalanced, Summing Line Level Inputs
- Balanced Mic/Line/Tel Input w/ Phantom Power
- Automated Diagnostic System Test (Push Here Diagnostic)
| Frequency Response | 80Hz - 15kHz |
|---|---|
| Connector Type | 4 Position Phoenix 3.5mm Pitch |
| Power Output | Max. Average Power @ 80Hz-15kHz with .5% THD, 4Ω 50W RMS |
| Height | 3.66" (93mm) |
| Width | 8.27" (210mm) |
| Depth | 10.87" (276mm) |
| Weight | 10.5ib |
| Shipping Weight | 12.4lb |
| Voltage Compatibility | 220V - 240V |
| Warranty Period | 36 months from date of purchase |
