Item # KLR-2000
2CH POWER AMPLIFIER 1000W @ 2, 600W @ 4, 350W @ 8 OHMS, 2RU
Item # KLR-2000
2CH POWER AMPLIFIER 1000W @ 2, 600W @ 4, 350W @ 8 OHMS, 2RU
- UM: EA
- Estimated Weight: 30.0
- Brand: ASHLY
The Ashly KLR-2000 is a high-performance 2-channel power amplifier designed for professional audio applications in live sound, installed systems, and touring setups. Delivering 1000W per channel at 2 ohms, this Class AB amplifier provides efficient, clean power with low distortion and high dynamic range. Built with a rugged 2U rack-mountable chassis, the KLR-2000 features XLR and 1/4-inch TRS inputs, along with Speakon® outputs for flexible connectivity. Advanced cooling technology ensures reliable operation even in demanding environments. Ideal for houses of worship, theaters, nightclubs, stadiums, and large venues, this amplifier offers exceptional sound quality and long-term durability.
Ashly's KLR Series high-efficiency, high-power amplifiers are the ideal choice for high-output speaker systems, line arrays, dual 18” subwoofers and much more. KLRs are quiet, with signal-to-noise ratio ratings from >108 dB to >110 dB across all models. Each with a 3-position gain switch for both channels, a 3-position mode switch (bridged, stereo or parallel mono) and a 3-position 12dB/oct HPF switch (30Hz, 50Hz or off).
Features
- Optimized to deliver high levels of sustained power
- Rated for 2 Ohms operation
- Balanced inputs via 3-pin Euroblock
- Combo XLR/TRS connectors
- Neutrik® speakON® type output connectors
- Switch-mode power supply with extensive protection circuitry
- On/off limiter switch
- Forced-air cooled (front-in, rear-out)
- Removable dust filters, easy to clean
- Front-mounted attenuators
- Removable amp handles for permanent installation
- Optional locking front panel volume knobs
- Safety/Compliance: cCSAus, CE, FCC, RoHS
- KLR-2000 output topology: Class-AB; KLR-3200, 4000, and 5000 output topology: 2-step Class-H design
|
KLR Models |
2000 |
3200 |
4000 |
5000 |
|
Max Output Power: Per Channel, 20HZ-20KHz, 1%THD, Both Channels Driven | ||||
|
2 Ohms |
1,000W |
1,600W |
2,000W |
2,500W |
|
4 Ohms |
600W |
1,100W |
1,400W |
1,700W |
|
8 Ohms |
350W |
650W |
850W |
1,000W |
|
Bridge Mode, 20Hz-20KHz, 1%THD | ||||
|
4 Ohms |
2,000W |
3,200W |
4,000W |
5,000W |
|
Constant Voltage Options: Per Channel, 20Hz-20KHz, 1%THD | ||||
|
70V |
- |
800W* |
- |
- |
|
Line Current Draw: 120VAC 60Hz, All Channels Driven @ 4 Ohms | ||||
|
Idle |
0.99A |
0.92A |
1.05A |
1.14A |
|
1/8th Power (Pink Noise |
9.7A |
11.4A |
14.0A |
17.5A |
|
1/3 Power (Sine Wave) |
14.9A |
16.6A |
19.8A |
24.7A |
|
Thermal Dissipation: BTU/hr, All Channels Driven | ||||
|
Idle |
164 |
136 |
171 |
215 |
|
1/8th Power (Pink Noise |
1,876 |
2,063 |
2,489 |
3,111 |
|
1/3 Power (Sine Wave) |
2,880 |
3,001 |
3,516 |
4,395 |
|
Additional Specs | ||||
|
Signal-to-Noise (10Hz-20KHz, unweighted) |
>108dB |
>109dB |
>109dB |
>110dB |
|
Inpout Gain Switch |
1V, |
1V, |
1V, |
1V, |
|
Output Circuitry |
Class AB |
2-Step Class H |
2-Step Class H |
2-Step Class H |
